III. Millimeter and Submillimeter Techniques

1."Extension of Microwave Absorption Spectroscopy to 0.37-Millimeter Wavelength," Phys. Rev. Lett. 25, 1397-1399 (1970).

  -   The standard spectrometer for much of SMM/THz spectroscopy:  Frequency multiplication from a lower frequency source and a sensitive cryogenic detector

2. "Molecular Beam Maser for the ShortMillimeter Wave Region:  Spectral Constants of HCN and DCN," Phys. Rev. 187, 58-65 (1969).

   -   A high resolution molecular beam maser for the SMM/THz

"Microwave Generation from Picosecond Demodulation Sources," Appl. Phys. Lett. 47, 894-896 (1985)."Femtosecond Demodulation Source for High Resolution Submillimeter Spectroscopy,"  Appl. Phys. Lett.  67, 3810 (1995). "Modulating and scanning the mode-lock frequency of an 800-MHz femtosecond Ti:sapphire laser,"  Optics Letters 24, 250 - 252 (1999).

  -  Femtosecond demo sdulation for comb generation in the SMM/THz

4.  "A Fast Scan Submillimeter Spectroscopic Technique," Rev. Sci. Instrum. 68, 1675 (1997).

   -   The Fast Scan Submillimeter Spectroscopy Technique (FASSST) for the rapid (a few seconds) acquisition of 'complete' spectra in the SMM/THz

5. "Noise, detectors, and submillimeter-terahertz system performance in nonambient environments," J. Opt. Soc. 21A, 1273 (2004).

   -   Noise in the SMM/THz:  Contrary to conventional wisdom, the SMM/THz is a remarkably quiet spectral region for spectroscopy and sensing

6. "Continuously tunable coherent spectroscopy for the 0.1 to 1.0 THz region," Appl. Phys. Lett. 42, 309-310 (1983).

     As is well known, the THz spectral region is by far the least explored portion of the electromagnetic spectrum, largely because of the difficulty of generating and detecting radiation at these frequencies. In fact, Townes has pointed out that his original motivation for the development of the maser/laser was his desire to make a 'molecular generator' to overcome this problem.1 Although thermal, or nearly thermal, 2 photons have always existed in the THz, the problem is one of generating 'appropriate' radiation, not only in terms of power, but also spectral purity. In this section , we will focus on those properties important for the development of spectroscopic applications and the development of useful spectroscopic systems. Because there is an intimate interplay between the development of appropriate THz sources and the spectroscopic studies themselves, we will also use this section to discuss laboratory spectroscopic results. These will include studies of the basic spectroscopy of small, fundamental species, the production and study of free radicals and ions, and the study of collisional processes.  Figure III-1 shows an overview of the power available from representative sources as a function of frequency. 3   While at first it might seem that these power levels are so low as to preclude scientific work over much of the region, this is far from the case. Most spectroscopic measurements are linear, and as a result it is possible to trade detector sensitivity for source power. The initial measurements in this spectral region were made by the use of point contact detectors, 4 which in their more modern microelectronic fabricated form 5 have been rechristened as Schottky barrier diodes and are still an important tool. The next important step in the development of spectroscopic systems in this region was the introduction of cryogenic detectors, (6)

Text Box:  										  Figure III-1.  Available power from solid state sources as a function of frequency .

especially the InSb hot electron bolometer because of its speed ( t < 10-6 sec) and sensitivity (~10-12 W/Hz-1/2) . Additionally, the much higher reliability of the cryogenic detectors made work in this spectral region much less of a 'black art' and made THz science more accessible to non-specialists. In most configurations the sensitivity of the InSb detectors begins to decrease above ~300 GHz and the slower (~10-3 sec) Si and Ge bolometers become more advantageous in many systems.7 Additionally, bolometers rapidly gain sensitivity with decreasing temperature and cooling them to 3He temperatures (~300 mK) can increase their NEPs 8 In this limit these detectors approach the sensitivity limit set by the fluctuations in the blackbody background.9-12 (9) (12) Heterodyne detectors can be even more sensitive and in many cases can approach the quantum limit. However, for laboratory spectroscopy they in some sense beg the question of available power because of their requirements for local oscillator power. However, for remote sensing applications they have been developed to a very high degree and we will discuss them in this context in Section V below.

     A very large majority of THz studies have taken advantage of the   high Q 's (~106 ) associated with spectral lines of low pressure gases. Consequently, correspondingly high spectral purity has been a requirement for most THz laboratory spectroscopic systems, as well as for their corresponding field applications. Approaches to the high Q source problem have included a series of advances in nonlinear frequency multiplication and cooled detector development, 4,6, 8, 13 (4) (6) (8) the extension of fundamental electron beam oscillators 14,15 and fundamental solid state oscillators to higher frequency, 16,17 (16) (17) optical heterodyne down conversion, 18-22(18)(19) (21) (22) the production of microwave sidebands on FIR laser sources, 23-27 (23) (24) (25) (26) (27) and the demodulation of femtosecond laser pulse trains. ( 28) (29)


     In the following sections  we will discuss those techniques which have been the most widely used to illustrate results typical of high resolution spectroscopy and its applications  in the THz. Because virtually all of the systems we will discuss make use of the cryogenic detectors discussed above, we will organize this section according to source technology.

OSU Physics Department |The College of Mathand Physical Sciences The Ohio State University




[1] C. H. Townes, How the Laser Happened:  Adventures of a Scientist. New York: Oxford, 1999.

[2] E. F. Nichols and J. D. Tear, "Short Electric Waves," Phys. Rev., vol. 21, pp. 587-610, 1923.

[3] E. Brown, private communication, 2001.

[4] W. C. King and W. Gordy, "One to Two Millimeter Wave Spectroscopy.  I.," Phys. Rev., vol. 90, pp. 319-320, 1953.

[5] C. A. Burrus Jr., "Millimeter-Wave Point-Contact and Junction Diodes," Proc. IEEE, vol. 54, pp. 575-587, 1966.

[6] P. Helminger, F. C. De Lucia, and W. Gordy, "Extension of Microwave Absorption Spectroscopy to 0.37-mm Wavelength," Phys. Rev. Lett., vol. 25, pp. 1397-1399, 1970.

[7] K. M. Evenson, D. A. Jennings, K. R. Leopold, and L. R. Zink, in Seventh International Conference on Laser Spectroscopy, T. W. Hansch and Y. R. Shen, Eds. Berlin: Springer, 1985, pp. 300.

[8] P. Helminger, J. K. Messer, and F. C. De Lucia, "Continuously Tunable Coherent Spectroscopy for the 0.1- to 1.0-THz Region," Appl. Phys. Lett., vol. 42, pp. 309-310, 1983.

[9] W. B. Lewis, "Fluctuations in Streams of Thermal Radiation," Proc. Phys. Soc., vol. 59, pp. 34-40, 1947.

[10] E. H. Putley, "The Ultimate Sensitivity of Sub-mm Detectors," Infrared Physics, vol. 4, pp. 1-8, 1964.

[11] E. H. Putley, "Far Infra-Red Photoconductivity," Phys. Stat. Solids, vol. 6, pp. 571-614, 1964.

[12] E. H. Putley, "Indium Antimonide Submillimeter Photoconductive Detectors," Applied Optics, vol. 4, pp. 649-657, 1990.

[13] F. Lewen, S. P. Belov, F. Maiwald, T. Klaus, and G. Winnewisser, "A Quasi-Optical Multiplier for Terahertz Spectroscopy," Z. Naturforsch, vol. 50a, pp. 1182-1186, 1995.

[14] A. Karp, "Backward-Wave Oscillator Experiments at 100 and 200 Kilomegacycles," Proc. I. R. E., vol. 45, pp. 496-503, 1957.

[15] M. B. Golant, Z. T. Alekseenko, Z. S. Korotkova, L. A. Lunkina, A. A. Negirev, O. P. Petrova, T. B. Rebrova, and V. S. Savel'ev, "Wide-Range Oscillators for the Submillimeter Wavelengths," Pribory i Tekhnika Éksperimenta, vol. 3, pp. 231-237, 1969.

[16] M. Ino, T. Ishibashi, and M. Ohmori, "Submillimeter wave Si p+-p-n+ IMPATT diodes," Jpn. J. Appl. Phys. Suppl., vol. 16-1, pp. 89-92, 1977.

[17] E. R. Brown, J. R. Soderstrom, C. D. Parker, L. J. Mahoney, K. M. Molvar, and T. C. McGill, "Oscillations up to 712 GHz in InAS/AlSb resonant-tunneling diodes," Appl. Phys. Lett., vol. 58, pp. 2291-2293, 1991.

[18] K. M. Evenson, D. A. Jennings, and F. R. Peterson, "Tunable far-infrared spectroscopy," Appl. Phys. Lett., vol. 44, pp. 576-578, 1984.

[19] E. R. Brown, K. A. McIntosh, K. B. Nichols, and C. L. Dennis, "Photomixing up to 3.8 THz in low-temperature-grown GaAs," Appl. Phys. Lett., vol. 66, pp. 285-287, 1995.

[20] A. S. Pine, R. D. Suenram, E. R. Brown, and K. A. McIntosh, "A Terahertz Photomixing Spectrometer - Applications to SO2 Self-broadening," J. Mol. Spectrosc., vol. 175, pp.37-47, 1996.

[21] S. Matsuura, G. A. Blake, R. A. Wyss, J. C. Pearson, C. Kadow, A. W. Jackson, and A. C. Gossard, "A Traveling-Wave THz Photomixer Based on Angle-Tuned Phase Matching," Appl. Phys. Lett., vol. 74, pp. 2872, 1999.

[22] S. Matsuura, P. Chen, G. A. Blake, J. C. Pearson, and H. M. Pickett, "A Tunable Cavity-Locked Diode Laser Source for Terahertz Photomixing," IEEE Trans.      Microwave Theory and Tech., vol. 48, pp. 380-387, 2000.

[23] D. D. Bicanic, B. F. J. Zuidberg, and A. Dymanus, "Generation of continuously tunable laser sidebands in the submillimeter region," Appl. Phys. Lett., vol. 32,    pp. 367-369, 1978.

[24] W. A. M. Blumberg, H. R. Fetterman, D. D. Peck, and P. F. Goldsmith, "Tunable submillimeter sources applied to the excited state rotational spectroscopy and kinetics of CH3F," Appl. Phys. Lett., vol. 35, pp. 582-585, 1979.

[25] J. Farhoomand, G. A. Blake, M. A. Frerking, and H. M. Pickett, "Generation of tunable laser sidebands in the far-infrared region," J. Appl. Phys., vol. 57, pp. 1763-1768, 1985.

[26] P. Verhoeve, E. Zwart, M. Versluis, J. ter Meulen, W. L. Meerts, A. Dymanus, and D. Mclay, "A far infrared laser sideband spectrometer in the frequency region 550 - 2700 GHz," Rev. Sci. Instrum., vol. 61, pp. 1612-1625, 1990.

[27] G. A. Blake, K. B. Laughlin, R. C. Cohen, K. L. Busarow, D.-H. Gwo, C. A. Schmuttenmaer, D. W. Steyert, and R. J. Saykally, "Tunable Far Infrared Laser Spectrometers," Rev. Sci. Instruments, vol. 62, pp. 1693-1700, 1991.

[28] F. C. De Lucia, B. D. Guenther, and T. Anderson, "Microwave Generation from Picosecond Demodulation Sources," Appl. Phys. Lett., vol. 47, pp. 894-896, 1985.

[29] T. M. Goyette, W. Guo, F. C. De Lucia, J. Swartz, H. O. Everitt, B. D. Guenther, and E. R. Brown, "Femtosectond Demodulation Source for High Resolution Submillimeter Spectroscopy," Appl. Phys. Lett., vol. 67, pp. 3810, 1995.
